Target Time Display - Elimination or Score Mode
Targets must be positioned in the normal ShowDown configuration:
4 5 6 3 2 1
If you will shoot three pairs elimination separate the targets:
4 5 6 3 2 1
The target cables are connected to the CPU in the normal manner.
Gold tape has been affixed to the Timer lens to clearly identify the shooter pairs.
The lower left box is the LED displays for the two shooters at Range Left.
Green target LED 4 – 5. (4 is the left shooter of the pair.)
The top center box is the LED displays for the two shooters at Range Center.
Green target LED 6 – 3. (6 is the left shooter of the pair.)
The lower right box is the LED displays for the two shooters at Range Right.
Green target LED 2 – 1. (1 is the right shooter of the pair.)
